Validation
A modelling tool can claim anything about MODFLOW. What it cannot fake is a list of published models, written by other people, that it opens, writes back and runs. These are the models GWlink is tested against: the MODFLOW 6 example suite, FloPy's own test models and the GMDSI tutorials, each linked to where it came from.
MODFLOW 6 examples
github.com/MODFLOW-USGS/modflow6-examplesAdvanced Tidal
MODFLOW 6
DISV · IC · NPF · IMS · OC · CHD · WEL · RCH · EVT · GHB
Advanced TidalCLIP
BCF2 Steady-State
MODFLOW 6
DIS · IC · NPF · IMS · OC · CHD · WEL · RCH
BCF2 Steady-StateCLIP
TWRI
MODFLOW 6
DIS · IC · NPF · IMS · OC · CHD · WEL · DRN · RCH
TWRICLIP
Flow and Head Boundary Replication
MODFLOW 6
DIS · IC · NPF · STO · IMS · OC · CHD · WEL · OBS · TS
Flow and Head Boundary ReplicationCLIP
Capture Fraction Analysis
MODFLOW 6
DIS · IC · NPF · IMS · OC · CHD · WEL · RIV · RCH
Capture Fraction AnalysisCLIP
MODFLOW-NWT Problem 3 High Recharge
MODFLOW 6
DIS · IC · NPF · IMS · OC · CHD · RCH
MODFLOW-NWT Problem 3 High RechargeCLIP
Flow Diversion Newton
MODFLOW 6
DIS · IC · NPF · IMS · OC · CHD
Flow Diversion NewtonCLIP
MODFLOW-NWT Problem 2 Newton
MODFLOW 6
DIS · IC · NPF · STO · IMS · OC · CHD · RCH
MODFLOW-NWT Problem 2 NewtonCLIP
Zaidel Drainage Problem
MODFLOW 6
DIS · IC · NPF · IMS · OC · CHD
Zaidel Drainage ProblemCLIP
Horizontal Anisotropy Reference
MODFLOW 6
DIS · IC · NPF · IMS · OC · CHD · WEL
Horizontal Anisotropy ReferenceCLIP
Whirl Flow
MODFLOW 6
DIS · IC · NPF · IMS · OC · WEL
Whirl FlowCLIP
11 models.
Freyberg MODFLOW-USG
MODFLOW-USG
3 layers · 4,497 cells · 25 stress periods
DISU · BAS · LPF · SMS · OC · WEL · GHB · RCH · SFR · GNC
Freyberg MODFLOW-USGCLIP
MF6 Tutorial 01
MODFLOW 6
1 layers
DIS · IC · NPF · IMS · OC · CHD · RCH
MF6 Tutorial 01CLIP
FloPy Structured Grid Demo
MODFLOW 6
DIS · IC · NPF · IMS · OC · CHD
FloPy Structured Grid DemoCLIP
FloPy Budget Example
MODFLOW 6
DIS · IC · NPF · STO · IMS · OC · CHD · WEL
FloPy Budget ExampleCLIP
FloPy Formhead
MODFLOW 6
DIS · IC · NPF · IMS · OC · CHD
FloPy FormheadCLIP
FloPy Time Demo
MODFLOW 6
DIS · IC · NPF · STO · IMS · OC
FloPy Time DemoCLIP
FloPy Splitter Model
MODFLOW 6
DIS · IC · NPF · IMS · OC · CHD · WEL
FloPy Splitter ModelCLIP
Freyberg USG with Outputs
MODFLOW-USG
DISU · BAS · LPF · SMS · OC · WEL · GHB · RCH
Freyberg USG with OutputsCLIP
lakeex2a — MF6 SFR 22-reach chain coupled to LAK via MVR
MODFLOW 6
5 layers · 1 stress period
DIS · IC · NPF · STO · IMS · OC · CHD · EVT · RCH · SFR · LAK · MVR
lakeex2a — MF6 SFR 22-reach chain coupled to LAK via MVRCLIP
9 models.
GMDSI tutorials
github.com/gmdsi/GMDSI_notebooksGMDSI Milford MFUSG
MODFLOW-USG
3 layers · 190,080 cells · 1 stress period
BAS · DISU · LPF · SMS · OC · RCH · EVT · WEL · RIV · DRN · CLN
GMDSI Milford MFUSGCLIP
1 model.
GWLab
Built here, to cover what the published suites do notDISV Voronoi Grid
MODFLOW 6
DISV · IC · NPF · IMS · OC
DISV Voronoi GridCLIP
Freyberg TVM (Time-Varying Materials)
MODFLOW-USG
DISU · BAS · LPF · SMS · OC · WEL · GHB · RCH
Freyberg TVM (Time-Varying Materials)CLIP
HFB MFUSG
MODFLOW-USG
DISU · BAS · LPF · SMS · OC · HFB
HFB MFUSGCLIP
HFB MF6 DISV
MODFLOW 6
DISV · IC · NPF · IMS · OC · HFB · CHD
HFB MF6 DISVCLIP
HFB Rich MF6
MODFLOW 6
DISV · IC · NPF · IMS · OC · HFB · CHD · WEL · RCH
HFB Rich MF6CLIP
HFB Rich MFUSG
MODFLOW-USG
DISU · BAS · LPF · SMS · OC · HFB · CHD · WEL · RCH
HFB Rich MFUSGCLIP
CLN Vertical Wells MFUSG
MODFLOW-USG
DISU · BAS · LPF · SMS · OC · CLN · WEL
CLN Vertical Wells MFUSGCLIP
MODFLOW-USG CLN Conduit Well (Example 3a)
MODFLOW-USG
3 layers · 30,000 cells · 1 stress period
DISU · BAS · LPF · SMS · OC · CLN · WEL
MODFLOW-USG CLN Conduit Well (Example 3a)CLIP
MAW MF6 DISV
MODFLOW 6
2 layers · 1 stress period
DISV · IC · NPF · STO · IMS · OC · MAW · CHD
MAW MF6 DISVCLIP
9 models.
What this proves, and what it does not
Each model is imported, written back out and run, and the run is expected to converge. That is a strong check on the file layer: it catches a package silently dropped, an array reshaped, a stress period lost. It is not a claim that GWlink reproduces every published result to the last decimal, and it says nothing about whether your own model is a good model. It says the software gives you back what you gave it.
Where a package is only carried through rather than interpreted, the specifications say so package by package.
30 models in the suite, 21 of them published by others, 30 expected to converge.
If you have a model that ought to be on this list, it is worth saying so when you write.
GWlink is in private beta, by invitation.
